新型有机-无机杂化涂层-气相色谱/质谱联用测定正构烷烃性能研究
Determination of n-alkanes by Gas Chromatograph-Mass Spectrometry Coupled Solid Phase Microextraction with a New Organic/Inorganic Composite Coating
-
摘要: 水体中正构烷烃的含量反映了研究区域有机物污染水平。痕量正构烷烃的测定常常需要结合分离富集方法才能保证灵敏度和选择性,液液萃取等常规分离富集方法存在耗时长、有机溶剂使用量大等缺点,而新型固相微萃取(SPME)分离富集技术相比而言具有高效简便、富集效率高的特点。本文采用溶胶-凝胶法自制稳定性和耐基质性能更优的有机-无机杂化SPME涂层,结合气相色谱-质谱(GC-MS)检测技术,对水样中26种正构烷烃进行同时测定。在优化的SPME-GC/MS条件下,采用浸入式萃取方式,萃取温度为25℃,萃取时间为30 min,26种正构烷烃的分析信号与浓度之间有良好的线性关系(线性相关系数为0.9935~0.9999),方法检出限为0.011~0.085 μg/L(k=3),相对标准偏差(RSD,n=5)为3.9%~10.0%。新型有机-无机杂化涂层与传统的分离富集技术相比,减少了有机溶剂的使用,提高了工作效率;与商用PDMS涂层相比,增加了正构烷烃同时检测的种类,提高了灵敏度,检出限低2~10倍。自制的有机-无机杂化SPME涂层体现出优异的分析性能和应用潜力。Abstract: Concentrations of n-alkanes in water often indicate the degree of organic pollution in a specific region. Trace n-alkanes analysis is often associated with the separation and enrichment process in order to improve the sensitivity and selectivity of the method. The conventional separation and enrichment methods, such as liquid-liquid extraction, are time-consuming and utilize a large quantity of organic solvents. Conversely, the Solid Phase Microextraction (SPME) technology has the characteristics of high efficiency and high sensitivity. A new method of determining 26 n-alkanes by using a homemade organic-inorganic hybrid solid phase microextraction coating combined with Gas Chromatography-Mass Spectrometry (GC-MS) has been established. The homemade SPME coating produced by the sol-gel method has good stability and is matrix resistant. The optimized analytical conditions were 30 min of extraction at 25℃ in immersion extraction mode. Under the optimized conditions of SPME-GC-MS, analysis signals of all 26 n-alkanes had good linear relationships with the concentration. The linear correlation coefficient r ranged from 0.9935 to 0.9999. The detection limits (k=3) were in the range of 0.011 to 0.085 (μg/L), and the relative standard deviations (RSD, n=5) ranged between 3.9% and 10.0%. The results show that the detection limits of 26 n-alkanes with homemade organic-inorganic hybrid coating were 2-10 times lower than the commercial PDMS coating, and more types of n-alkane were simultaneously determined with high sensitivity. The method is simple, fast, sensitive and easy to use in the determination of n-alkanes. The homemade organic-inorganic hybrid SPME coating shows excellent performance of n-alkanes analysis and potential applications.
-
Keywords:
- n-alkanes /
- organic-inoganic /
- composite /
- coating
-
-
蒲阳,张虎才,王永莉,雷国良, Nace T, 张淑萍.青藏高原冰蚀湖沉积物正构烷烃记录的气候和环境变化信息: 以希门错为例[J].科学通报, 2011, 56(14): 1132-1139. 王欢业,刘卫国,张普.地质样品正构烷烃组分分离纯化的部分问题探究[J].岩矿测试, 2011, 30(1): 13-22. Duan Y, Wu B, Xu L, He J, Sun T. Characterisation of n-alkanes and their hydrogen isotopic composition in sediments from Lake Qinghai, China[J]. Organic Geochemistry, 2011, 42: 720-726. Duan Y, Wu B, Xu L, He J, Sun T. Characterisation of n-alkanes and their hydrogen isotopic composition in sediments from Lake Qinghai, China[J]. Organic Geochemistry, 2011, 42: 720-726.
Souza D B D, Machado K S, Froehner S. Distribution of n-alkanes in lacustrine sediments from subtropical lake in Brazil[J]. Chemie der Erde, 2011, 71: 171-176. Souza D B D, Machado K S, Froehner S. Distribution of n-alkanes in lacustrine sediments from subtropical lake in Brazil[J]. Chemie der Erde, 2011, 71: 171-176.
Huang X, Xue J. Long chain n-alkanes and their carbon isotopes in lichen species from western Hubei Province: Implication for geological records [J]. Frontiers of Earth Science, 2012,6(1): 95-100. Huang X, Xue J. Long chain n-alkanes and their carbon isotopes in lichen species from western Hubei Province: Implication for geological records [J]. Frontiers of Earth Science, 2012,6(1): 95-100.
朱纯,潘建明,卢冰,扈传昱,刘小涯,叶新荣,薛斌.长江口及邻近海域现代沉积物中正构烷烃分子组合特征及其对有机碳运移分布的指示[J].海洋学报, 2005, 27(4): 59-67. 徐超.广州市及其周边城市中小型水库和湖泊正构烷烃监测[J].安徽农业科学, 2011, 39(31): 19372-19374. 梁波,张凯,沈汝浪,曾永平.珠江三角洲外围水体中正构烷烃的来源分析和通量估算: 加强珠江上游区域生态环境保护的必要性[J].地球化学, 2012, 41(1): 55-62. 戚艳平,吴莹, 张经,何青.夏季长江口中颗粒态及溶解态正构烷烃组成和迁移[J].环境科学学报, 2006, 26(8): 1354-1361. 杨佰娟,徐晓琴,李庆玲,何鹰,黎先春,王小如.气相色谱质谱联用技术在海面溢油事故鉴别中的应用——案例分析[J].海洋环境科学, 2008, 27(6): 661-665. 高连存,崔兆杰,魏英勤.固相萃取-气相色谱法测定水样中痕量正构烷烃的研究[J].安全与环境学报, 2002, 2(3): 37-39. Arthur C L, Pawliszyn J. Solid phase microextraction with thermal desorption using fused silica optical fibers [J].Analytical Chemistry, 1990, 62 (19): 2145-2148. Arthur C L, Pawliszyn J. Solid phase microextraction with thermal desorption using fused silica optical fibers [J].Analytical Chemistry, 1990, 62 (19): 2145-2148.
Ouyang G, Vuckovic D, Pawliszyn J. Nondestructive sampling of living systems using in vivo solid-phase microextraction [J]. Chemical Reviews,2011,111(4): 2784-2814. Ouyang G, Vuckovic D, Pawliszyn J. Nondestructive sampling of living systems using in vivo solid-phase microextraction [J]. Chemical Reviews,2011,111(4): 2784-2814.
蒋生祥,冯娟娟.固相微萃取研究进展[J].色谱, 2012, 30(3): 219-221. Rafieiolhossaini M, Adams A S H. Fast quality assess-ment of German chamomile (Matricaria chamomilla L.) by headspace solid-phase micro-extraction: Influence of flower development stage[J]. Natural Product Commun-ications,2012, 1(7): 97-100. Rafieiolhossaini M, Adams A S H. Fast quality assess-ment of German chamomile (Matricaria chamomilla L.) by headspace solid-phase micro-extraction: Influence of flower development stage[J]. Natural Product Commun-ications,2012, 1(7): 97-100.
解万翠,杨锡洪,章超桦,吉宏武,张丽风.顶空固相微萃取-气相色谱-质谱法测定北极虾虾头的挥发性成分[J].分析化学, 2011, 39(12): 1852-1857. Farajzadeh M, Matin A A. A new PVC-activated char-coal fiber coated on silver wire; application in determination of n-alkanes in the headspace of soil samples by SPME-GC[J]. Analytical Sciences,2002, 18(1): 77-81. Farajzadeh M, Matin A A. A new PVC-activated char-coal fiber coated on silver wire; application in determination of n-alkanes in the headspace of soil samples by SPME-GC[J]. Analytical Sciences,2002, 18(1): 77-81.
Farajzadeh M, Hatami M. Analysis of n-alkanes at sub microgram per liter level after direct solid phase microextraction[J]. Analytical Sciences, 2002,18(11): 1221-1225. Farajzadeh M, Hatami M. Analysis of n-alkanes at sub microgram per liter level after direct solid phase microextraction[J]. Analytical Sciences, 2002,18(11): 1221-1225.
陆文琼.固相微萃取技术在循环水系统微量泄漏油烃分布检测中的应用[J].石油炼制与化工, 2005, 36(3): 51-54. Mehdinia A, Asiabi M, Jabbari A, Kalaeec M R. Preparation and evaluation of solid-phase microextraction fiber based on nano-structured copolymer of aniline and m-amino benzoic acid coating for the analysis of fatty acids in zooplanktons[J].Journal of Chromatography A, 2010, 1217(49): 7642-7647. Mehdinia A, Asiabi M, Jabbari A, Kalaeec M R. Preparation and evaluation of solid-phase microextraction fiber based on nano-structured copolymer of aniline and m-amino benzoic acid coating for the analysis of fatty acids in zooplanktons[J].Journal of Chromatography A, 2010, 1217(49): 7642-7647.
Zhang H, Lee H K. Plunger-in-needle solid-phase micr-oextraction with graphene-based sol-gel coating as sorbent for determination of polybrominated diphenyl ethers[J].Journal of Chromatography A, 2010, 1218(28): 4509-4516. Zhang H, Lee H K. Plunger-in-needle solid-phase micr-oextraction with graphene-based sol-gel coating as sorbent for determination of polybrominated diphenyl ethers[J].Journal of Chromatography A, 2010, 1218(28): 4509-4516.
观文娜,许峰,廉玫,徐媛,关亚风.聚甲基三氟丙基硅氧烷固相微萃取涂层的制备及其对海水中酚类化合物的分析[J].色谱, 2007, 25(5): 614-618. 黄健祥,胡玉玲,李攻科.选择性固相微萃取涂层的研究进展[J].分析科学学报, 2008, 24(1): 97-102. 张茂升,龚丽芬,余彬彬,曾景斌,袁宁,陈曦.超声提取-超声波辅助固相微萃取色谱法测定蔬菜中的有机氯、菊酯类农药残留量[J].分析试验室, 2008, 27(4): 25-28. 孙银,张伟亚,邢钧,王承明.羧基化单壁碳纳米管涂层同时测定纯净水中的烷基酚和双酚A[J].分析化学, 2011, 39(9): 1432-1436. 顾涛,帅琴,高强,肖红艳,朱丹,汤志勇.新型固相微萃取装置的研制及在有机磷农药检测中的应用[J].岩矿测试, 2012, 31(1): 71-76.
