气相色谱-同位素比值质谱法测定天然气水合物气体单体碳氢同位素
Measurement of Carbon and Hydrogen Isotopes of Natural Gas Hydrate-Bound Gases by Gas Chromatography-Isotope Ratio Mass Spectrometry
-
摘要: 天然气水合物气体同位素组成数据是其气体成因、运移与积聚过程研究的重要参数。目前天然气水合物气体单体碳、氢同位素仪器分析技术主要借鉴天然气的分析方法,但对水合物气的分解、收集、储存等前处理技术缺乏系统研究。本文利用气相色谱-同位素比值质谱(GC-IRMS)技术,对比研究了顶空法、注射器法和排水法等水合物气体分解与收集方法的实用性,以及铝塑气袋和丁基橡胶塞密封的玻璃顶空瓶对分解气的储存效果。实验结果表明:在丁基橡胶塞密封的玻璃顶空瓶内真空分解且原位储存是水合物气体单体碳、氢同位素分析的最佳前处理方法。方法标准偏差为0.12‰~0.23‰ 、1.0‰~1.8‰ ;相对标准偏差(RSD,n=6)为0.38%~0.86% 、0.62%~1.00% 。通过对南海神狐海域、祁连山冻土区、人工合成水合物样品的分析测定,表明该方法简便实用、适用范围宽,可满足天然气水合物气体单体碳、氢同位素的分析要求。
-
关键词:
- 天然气水合物气体 /
- 碳氢同位素 /
- 气相色谱-同位素比值质谱法
Abstract: The isotopic compositions of natural gas hydrate-bound gases can provide valuable information about the origin, migration and accumulation process of the gases. At present, the instrumental analysis methods for carbon and hydrogen isotope of natural gas hydrate-bound gases mainly refer to that for the natural gases. However, there is a lack of comprehensive studies on the influences of preparation technologies such as decomposition, collection and storage. In this paper, a Gas Chromatography-Isotope Ratio Mass Spectrometry (GC-IRMS) method was established for the measurement of carbon and hydrogen isotope of natural gas hydrate-bound gases (C1-C3 , CO2). The practical applicability of different gas decomposition and collection methods (i.e. headspace, syring and drainage), and the storage effect of different decomposed gases' storage vessels (i.e. aluminum air bag, glass bottle with butyl rubber plug) were comparatively studied. The results indicate that the best preparation methods are vacuum headspace-decomposition and in situ storage. Good precision of δ13C-(C1-C3, CO2) and δD-(C1-C3) is in the range of 0.12‰-0.23‰ and 1.0‰-1.8‰ with relative standard deviations (RSD, n=6) of 0.38%-0.86% and 0.62%-1.00%, respectively. The method was successfully applied in the determination of gas isotopic compositions of natural gas hydrate-bound gases from the South China Sea, Qilian Mountain Permafrost and laboratory synthetic samples. This method is easy to operate, can be applied widely, and is suitable for the determination of isotopic compositions of hydrate-bound gases.-
Keywords:
- natural /
- gas /
- hydrate-bound
-
-
Sloan E D, Koh C A. Clathrate hydrates of natural gases[M].3rd edition. Boca Raton: CRC Press, 2007. Sloan E D, Koh C A. Clathrate hydrates of natural gases[M].3rd edition. Boca Raton: CRC Press, 2007.
贺行良,刘昌岭,王江涛,孟庆国,夏宁,业渝光.天然气水合物气体组成分析技术[J].海洋地质前沿,2011,29(6): 123-125. 黄霞,祝有海,卢振权,王平康.南海北部天然气水合物钻探区烃类气体成因类型研究[J].现代地质, 2010, 24(3): 576-580. Hachikubo A, Krylov A, Sakagami H, Minami H, Nunokawa Y, Shoji H, Matveeva T, Jin Y K, Obzhirov A. Isotopic composition of gas hydrates in subsurface sediments from offshore Sakhalin Island, Sea of Okhotsk[J].Geo-Marine Letters,2010,30(3): 313-319. Hachikubo A, Krylov A, Sakagami H, Minami H, Nunokawa Y, Shoji H, Matveeva T, Jin Y K, Obzhirov A. Isotopic composition of gas hydrates in subsurface sediments from offshore Sakhalin Island, Sea of Okhotsk[J].Geo-Marine Letters,2010,30(3): 313-319.
Milkov A V. Molecular and stable isotope compositions of natural gas hydrates: A revised global dataset and basic interpretations in the context of geological settings[J].Organic Geochemistry, 2005,36(5): 681-702. Milkov A V. Molecular and stable isotope compositions of natural gas hydrates: A revised global dataset and basic interpretations in the context of geological settings[J].Organic Geochemistry, 2005,36(5): 681-702.
Sassen R, Roberts H H, Carney R, Milkov A V, DeFreitasa D A, Lanoile B, Zhang C. Free hydrocarbon gas, gas hydrate, and authigenic minerals in chemosynthetic communities of the northern Gulf of Mexico continental slope: Relation to microbial processes[J].Chemical Geology,2004,205(3-4): 195-217. Sassen R, Roberts H H, Carney R, Milkov A V, DeFreitasa D A, Lanoile B, Zhang C. Free hydrocarbon gas, gas hydrate, and authigenic minerals in chemosynthetic communities of the northern Gulf of Mexico continental slope: Relation to microbial processes[J].Chemical Geology,2004,205(3-4): 195-217.
Pohlman J W, Canuel E A, Chapman N R, Spence G D, Whitica M J, Coffin R B. The origin of thermogenic gas hydrates on the northern Cascadia Margin as inferred from isotopic (13C/12C and D/H) and molecular composition of hydrate and vent gas[J].Organic Geochemistry,2005,36(5): 703-716. Pohlman J W, Canuel E A, Chapman N R, Spence G D, Whitica M J, Coffin R B. The origin of thermogenic gas hydrates on the northern Cascadia Margin as inferred from isotopic (13C/12C and D/H) and molecular composition of hydrate and vent gas[J].Organic Geochemistry,2005,36(5): 703-716.
Bourry C, Chazallon B, Charlou J L, Donval J P, Ruffine L, Henry P, Geli L, Cagatay M N, Inan S, Moreau M. Free gas and gas hydrates from the Sea of Marmara, Turkey: Chemical and structural characteri-zation[J].Chemical Geology,2009,264(1-4): 197-206. Bourry C, Chazallon B, Charlou J L, Donval J P, Ruffine L, Henry P, Geli L, Cagatay M N, Inan S, Moreau M. Free gas and gas hydrates from the Sea of Marmara, Turkey: Chemical and structural characteri-zation[J].Chemical Geology,2009,264(1-4): 197-206.
孟庆国,刘昌岭,业渝光,陈强.不同体系中甲烷水合物储气特性实验研究[J].世界科技研究与发展,2011,33(1): 25-28. 贺行良,夏宁,刘昌岭,王江涛,孟庆国.FID/TCD并联气相色谱法测定天然气水合物的气体组成[J].分析测试学报,2012( 待发表).
贺行良,刘昌岭,孟庆国,祝有海,业渝光,夏宁.祁连山冻土区天然气水合物气体组分的气相色谱法测定[J].地质通报,2011, 30(12): 7-12. 王东良,马成华,李剑, 李志生,张英,王义凤,李谨.取样装置对天然气碳同位素检测结果的影响[J].天然气地球科学,2010,21(2): 346-349. 业渝光,刘昌岭,贺行良,孟庆国,孙始财.水合物相平衡原位监测实验装置[P].中国:ZL 2011 20099338.9 [2011-01-07]. Lee J W, Kim Y S, Lee J D, Park D W,Kim H Y. Formation and decomposition of gas hydrates for the mixtures of methane-ethane/methane-propane[C]//Proceedings of the 6th International Conference on Gas Hydrates. Canada, 2008. Lee J W, Kim Y S, Lee J D, Park D W,Kim H Y. Formation and decomposition of gas hydrates for the mixtures of methane-ethane/methane-propane[C]//Proceedings of the 6th International Conference on Gas Hydrates. Canada, 2008.
