高温高压密闭溶样-电感耦合等离子体质谱法测定荧光粉中的杂质元素

张伟娜, 陆继龙, 段太成

张伟娜, 陆继龙, 段太成. 高温高压密闭溶样-电感耦合等离子体质谱法测定荧光粉中的杂质元素[J]. 岩矿测试, 2012, 31(1): 90-94.
引用本文: 张伟娜, 陆继龙, 段太成. 高温高压密闭溶样-电感耦合等离子体质谱法测定荧光粉中的杂质元素[J]. 岩矿测试, 2012, 31(1): 90-94.
shu
ZHANG Wei-na, LU Ji-long, DUAN Tai-cheng. Determination of Impurity Elements in Fluorescent Powders by Using High Temperature and High Pressure Digestion with Bomb-Inductively Coupled Plasma-Mass Spectrometry[J]. Rock and Mineral Analysis, 2012, 31(1): 90-94.
Citation: ZHANG Wei-na, LU Ji-long, DUAN Tai-cheng. Determination of Impurity Elements in Fluorescent Powders by Using High Temperature and High Pressure Digestion with Bomb-Inductively Coupled Plasma-Mass Spectrometry[J]. Rock and Mineral Analysis, 2012, 31(1): 90-94.
shu

高温高压密闭溶样-电感耦合等离子体质谱法测定荧光粉中的杂质元素

  • 1.

    吉林大学地球探测科学与技术学院, 吉林 长春 130026

  • 2.

    中国科学院长春应用化学研究所, 吉林 长春 130022

  • 3.

    吉林师范大学化学学院, 吉林 四平 136000

  • 4.

    吉林大学地球探测科学与技术学院, 吉林 长春 130026

  • 5.

    中国科学院长春应用化学研究所, 吉林 长春 130022

基金项目:

国家自然科学基金项目(20605021, 20975099)

Determination of Impurity Elements in Fluorescent Powders by Using High Temperature and High Pressure Digestion with Bomb-Inductively Coupled Plasma-Mass Spectrometry

  • 1.

    College of Geoexploration Science and Technology, Jilin University, Changchun 130026, China

  • 2.

    Changchun Institute of Applied Chemistry, Chinese Academy of Sciences, Changchun 130022, China

  • 3.

    College of Chemistry, Jilin Normal University, Siping 136000, China

  • 4.

    College of Geoexploration Science and Technology, Jilin University, Changchun 130026, China

  • 5.

    Changchun Institute of Applied Chemistry, Chinese Academy of Sciences, Changchun 130022, China

摘要

    摘要
  • 摘要: 提出了一种采用高温高压密闭溶样快速消解荧光粉晶体的前处理新方法。针对目前常用的稀土氧化物和稀土磷酸盐类、碱土金属铝酸盐类、碱土金属硅酸盐类四大类荧光粉,研究了消解时间、温度、消解溶剂种类和用量4个条件对样品消解程度的影响。采用电感耦合等离子体质谱法(ICP-MS)测定了最佳消解条件下消解的荧光粉中杂质元素Cu、Zn、Cd和Pb的含量。结果表明:稀土氧化物和稀土磷酸盐类荧光粉的最佳消解条件为 2 mL HCl溶剂中120℃下消解3 h;碱土金属铝酸盐类荧光粉的最佳消解条件为2 mL HCl溶剂中160℃下消解6 h;碱土金属硅酸盐类的最佳消解条件为2 mL HCl+0.5 mL HF溶剂中160℃下消解3 h。荧光粉中主要共存元素对所测杂质元素Cu、Zn、Cd和Pb的检测无干扰。该法线性范围宽、检出限低、灵敏度高,是荧光粉晶体中元素检测的较佳方法。
    Abstract: A new fast pretreatment method for crystal fluorescent powders which are digested by high temperature and high pressure ambient in bombs is discussed in this paper. The influence of four conditions: digested time, temperature, the species, and dosage of solvents on the digestion ability of four kinds of fluorescent powders, including rare earth oxides and rare earth phosphates, alkaline-earth metal aluminates and alkaline-earth metal silicates were studied. The contents of impurity elements Cu, Zn, Cd and Pb in these fluorescent powders which were digested in optimal conditions were determined by Inductively Coupled Plasma-Mass Spectrometry (ICP-MS). The results show that the optimal digestion conditions are 2 mL HCl, 120℃ and 3 h for rare earth oxide and rare earth phosphate fluorescent powder; 2 mL HCl, 160℃ and 6 h for alkaline-earth metal aluminate fluorescent powder; 2 mL HCl-0.5 mL HF, 160℃and 3 h for alkaline-earth metal silicate fluorescent powder. The major coexisting elements had no obvious influence on the determination of Cu, Zn, Cd and Pb, the method had wide linear ranges, low limits of detection and high sensitivity, and was an optimal analytical method for determining elements of phosphor crystals.
    • HTML全文
    • 参考文献(19)
  • 赵科,罗新宁,崔向中,夏天,鱼志坚,赵春雷,何涛,庄卫东.CCFL荧光粉的现状及其发展趋势[J].稀有金属,2008,32(2): 245-251.
    Wang F, Liu X G. Recent advances in the chemistry of lanthanide-doped upconversion nanocrystals[J]. Chemical Society Reviews, 2009, 38(4): 976-989.

    Wang F, Liu X G. Recent advances in the chemistry of lanthanide-doped upconversion nanocrystals[J]. Chemical Society Reviews, 2009, 38(4): 976-989.
    Fu L, Liu Z M, Liu Y Q, Han B X, Wang J Q, Hu P G, Cao L C, Zhu D B. Coating carbon nanotubes with rare earth oxide multiwalled nanotubes[J]. Advanced Materials, 2004, 16 (4): 350-352.

    Fu L, Liu Z M, Liu Y Q, Han B X, Wang J Q, Hu P G, Cao L C, Zhu D B. Coating carbon nanotubes with rare earth oxide multiwalled nanotubes[J]. Advanced Materials, 2004, 16 (4): 350-352.
    李建宇.稀土发光材料及其应用[M].北京:化学工业出版社,2003: 2.
    Nelson J A, Brant E L, Wagner M J. Nanocrystalline Y2O3 : Eu phosphors prepared by alkalide reduction[J]. Chemistry of Materials, 2003, 15 (3): 688-693.

    Nelson J A, Brant E L, Wagner M J. Nanocrystalline Y2O3 : Eu phosphors prepared by alkalide reduction[J]. Chemistry of Materials, 2003, 15 (3): 688-693.
    Zhang F, Braun G B, Shi Y F, Zhang Y C, Sun X H, Reich N O, Zhao D Y, Stucky G. Fabrication of Ag@SiO2@Y2O3:Er nanostructures for bioimaging: Tuning of the upconversion fluorescence with silver nanoparticles[J]. Journal of the American Chemical Society, 2010, 132(9): 2850-2851.

    Zhang F, Braun G B, Shi Y F, Zhang Y C, Sun X H, Reich N O, Zhao D Y, Stucky G. Fabrication of Ag@SiO2@Y2O3:Er nanostructures for bioimaging: Tuning of the upconversion fluorescence with silver nanoparticles[J]. Journal of the American Chemical Society, 2010, 132(9): 2850-2851.
    Wan J X, Wang Z H, Chen X Y, Mu L, Qian Y T. Shape-tailored photoluminescent intensity of red phosphor Y2O3: Eu3+ [J]. Journal of Crystal Growth, 2005, 284(3-4): 538-543.

    Wan J X, Wang Z H, Chen X Y, Mu L, Qian Y T. Shape-tailored photoluminescent intensity of red phosphor Y2O3: Eu3+ [J]. Journal of Crystal Growth, 2005, 284(3-4): 538-543.
    Joffina N, Dexpert-Ghysa J, Verelsta M, Baret G, Garcia A. The influence of microstructure on luminescent properties of Y2O3: Eu prepared by spray pyrolysis [J]. Journal of Luminescence, 2005, 113(3-4): 249-257.

    Joffina N, Dexpert-Ghysa J, Verelsta M, Baret G, Garcia A. The influence of microstructure on luminescent properties of Y2O3: Eu prepared by spray pyrolysis [J]. Journal of Luminescence, 2005, 113(3-4): 249-257.
    Chien W C. Synthesis of Y2O3: Eu phosphors by bicon-tinuous cubic phase process[J]. Journal of Crystal Growth, 2006, 290(2): 554-559.

    Chien W C. Synthesis of Y2O3: Eu phosphors by bicon-tinuous cubic phase process[J]. Journal of Crystal Growth, 2006, 290(2): 554-559.
    Xia G D, Zhou S M, Zhang J J, Wang S M, Xu J. Direct synthesis and intense luminescence of Y2O3: Eu nanophosphors by complexation combustion [J]. Chemistry Letters, 2005, 34(8): 1166-1167.

    Xia G D, Zhou S M, Zhang J J, Wang S M, Xu J. Direct synthesis and intense luminescence of Y2O3: Eu nanophosphors by complexation combustion [J]. Chemistry Letters, 2005, 34(8): 1166-1167.
    姜洪义,胡丹,姬同坤.合成制度对白光LED用硅酸盐Sr2SiO4:Eu荧光粉发光性能的影响[J].硅酸盐学报,2010,38(3): 446-450.
    Yan X C, Yu R B, Wang D, Deng J X, Chen J, Xing X R. Facile solvothermal synthesis of gear-shaped submicrostructured Y2O3:Eu3+phosphor [J]. Solid State Sciences, 2011, 13(5): 1060-1064.

    Yan X C, Yu R B, Wang D, Deng J X, Chen J, Xing X R. Facile solvothermal synthesis of gear-shaped submicrostructured Y2O3:Eu3+phosphor [J]. Solid State Sciences, 2011, 13(5): 1060-1064.
    Kunimi S, Fujihara S. Elaboration of blue-emitting blue pigments based on Eu2+/Co2+ codoped BaMgAl10O17 through the heterogeneous distribution of dopants[J]. Dyes and Pigments, 2011, 91 (1): 49-54.

    Kunimi S, Fujihara S. Elaboration of blue-emitting blue pigments based on Eu2+/Co2+ codoped BaMgAl10O17 through the heterogeneous distribution of dopants[J]. Dyes and Pigments, 2011, 91 (1): 49-54.
    胡圣虹,王秀季,葛文,李爱荣,靳兰兰,王晓红.电感耦合等离子体光谱/质谱联机同时测定多金属结核中常量、微量、痕量元素[J].分析化学,2004,32(9): 1139-1144.
    徐鹏,孙亚莉. Carius管密封溶样-等离子体质谱法测定环境样品中镓、锗、砷、硒、镉、锡、锑、碲、汞、铅和铋[J].分析化学,2010,38(4): 581-584.
    屈文俊,杜安道. 高温密闭溶样电感耦合等离子体质谱准确测定辉钼矿铼-锇地质年龄[J].岩矿测试,2003,22(4): 254-257

    ,262.
    杨红霞,马新荣,李冰,孙德忠.电感耦合等离子体光谱/质谱法测定环境样品中的硼[J].岩矿测试,2004,23(4): 273-277.
    苏明跃,杨丽飞,郭芬.高压密封微波消解-氢化物发生原子荧光光谱法测定锰矿中砷和汞含量[J].冶金分析,2010,30(12): 39-43.
    Zdenek S. Methods of decomposition in inorganic analy-sis [M]. Boca Raton, Florida: CRC Press Inc, 1989: 118-119.

    Zdenek S. Methods of decomposition in inorganic analy-sis [M]. Boca Raton, Florida: CRC Press Inc, 1989: 118-119.
