高能偏振能量色散-X射线荧光光谱法测定PM<sub>10</sub>大气颗粒物的组成

吉昂; 郑南; 王河锦; 徐子优; 李国会

高能偏振能量色散-X射线荧光光谱法测定PM₁₀大气颗粒物的组成

1.
中国科学院上海硅酸盐研究所, 上海 200050
2.
北京大学地球与空间科学学院, 北京 100871
3.
北京大学地球与空间科学学院, 北京 100871
4.
北京市环境保护监测中心, 北京 100044
5.
中国地质科学院地球物理地球化学勘查研究所, 河北廊坊 065000

计量
- 文章访问数: 1819
- HTML全文浏览量: 0
- PDF下载量: 1415
出版历程
- 收稿日期: 2010-11-16
- 修回日期: 2011-03-14

Determination of Composition in PM₁₀ Aerosols by High-Energy Polarized Energy-Dispersive X-ray Fluorescence Spectrometry

1.
Shanghai Institute of Ceramics, Chinese Academy of Sciences, Shanghai 200050, China
2.
School of Earth and Space Sciences, Peking University, Beijing 100871, China
3.
School of Earth and Space Sciences, Peking University, Beijing 100871, China
4.
Beijing Municipal Environmental Monitoring Center, Beijing 100044, China
5.
Institute of Geophysical and Geochemical Exploration, Chinese Academy of Geological Sciences, Langfang 065000, China

摘要

摘要: 为配合X射线衍射分析(XRD)方法对可吸入大气颗粒悬浮物(PM₁₀)的结晶物相进行定性和定量分析的研究工作,本文应用高能偏振能量色散X射线荧光光谱(HE- P-EDXRF)对Whatman玻璃纤维滤膜采集的PM₁₀颗粒物中主、次量元素进行定量分析,着重研究了空气滤膜空白值对测定PM₁₀颗粒物中组成的影响。结果表明,当玻璃纤维滤膜空白值中元素的面密度大于0.1 μg/cm²时,需使用玻璃纤维滤膜为载体的标准样品;元素的面密度小于0.1 μg/cm²时,可用聚碳酸脂膜为载体的标准样品。对HE-P-EDXRF谱仪测定PM₁₀颗粒物中痕量重元素进行探讨,将测定元素范围扩展到62个元素,其中Na、Mg、S、Y、Nd、Sm、Eu、Gd、Tb、Dy、Ho、Er、Tm、Yb、Lu的检岀限>0.1 μg/cm²;Ca、Cr、Mn、Fe、Co、Ni、Cu、Zn、Br和Rb的检岀限<0.01 μg/cm²;Cl、Al、Si、P、K、Sc、Ti、V、Ge、As、Br、Se、Sr、Zr、Mo、Pd、Rh、In、Nb、Ag、Cd、Te、Sb、Sn、Ba、Cs、La、Ce、Pr、Au、Pt、W、Tl、Pb、Bi、Th和U等元素检出限为0.1~0.01 μg/cm²。
- PM₁₀大气颗粒物 /
- 高能偏振能量色散-X射线荧光光谱法(HE-P-EDXRF) /
- Epsilon /
- 5 /
- X射线荧光光谱仪
Abstract: In order to coordinate with X-ray Diffractomer (XRD) research on analyzing the crystal phase of inhaled aerosol PM₁₀ qualitatively and quantitatively, a method of using High-Energy Polarized Energy-Dispersive X-ray Fluorescence Spectrometry (HE-P-EDXRF) was developed to quantitatively measure the major and minor elements in aerosol PM₁₀ collected on Whatman glass fiber filters. The study focused on the effect of the blank values of air filter membrane for the measurement compositions of aerosol PM₁₀. The results indicate that the standards with glass fiber membrane filter should be used as carriers if the elemental area density of the blank glass fiber filter is more than 0.1 μg/cm³, and the nuclepore polycarbonate aerosol membrane filter should be used if the elemental area density is less than 0.1 μg/cm³. The measurement of heavy trace elements using He-P-EDXRF was also investigated, and extended the scope of the measuring elements to 62. The detection limits of Na, Mg, S, Y, Nd, Sm, Eu, Gd, Tb, Dy, Ho, Er, Tm, Yb and Lu were more than 0.1 μg/m², the detection limits of Ca, Cr, Mn, Fe, Co, Ni, Cu, Zn, Br and Rb were less than 0.01 μg/m², and the detection limits of Cl, Al, Si, P, K, Sc, Ti, V, Ge, As, Br, Se, Sr, Zr, Mo, Pd, Rh, In, Nb, Ag, Cd, Te, Sb, Sn, Ba, Cs, La, Ce, Pr, Au, Pt, W, Tl, Pb, Bi, Th and U were 0.1-0.01 μg/cm².
- aerosol /
- PM₁₀ /
- /
- high-energy /
- polarized

HTML全文

参考文献(15)

崔凤辉,王少林,卜赛斌,汪妥璞,黄衍初.大气飘尘的X射线荧光光谱分析[J].环境化学,1983,2(3):52-58.

陈远盘. XRFS分析空气悬浮微粒中的痕量元素[J].环境化学,1991,10(6):56-63.

邹海峰,苏克,姜桂兰,肖国拾.大气颗粒样品主量和痕量元素的直接测定[J].环境化学,1998,17(5):494-499.

贾春明,马玉芹,朱显梅,孙敬亮.长春市总悬浮颗粒物元素组分及时空分布规律[J].长春理工大学报,2005,28(4):116-119.

彭秀红,倪师军,张成江,刘璐,李光滔,薛燕妮.成都市环境污染初探[J].地球与环境,2005,33(Z1):617-619.

赵厚银,邵尤义,姚强.北京市冬季部分住宅区内PM₁₀中化学元素研究[J].环境与健康杂志,2006,23(1):14-17.

李德禄,张元勋,李爱国,王荫松,张桂林,李燕.冬季上海吴淞地区大气颗粒物PM₁₀的元素主成分分析[J].核技术,2005,28(2):109-112.

张元勋,王荫松,王荫松,李燕,张桂林,张元茂,郑叶飞,山祖慈.上海冬季大气可吸入颗粒物的PIXE研究[J].中国环境科学,2005,25(Z1):1-5.

李晓林,岳伟生,刘江峰,万天敏,张桂林,李燕,黄宇营,何伟,华魏.应用同步辐射微束X射线荧光方法测定单个大气PM_2.5颗粒物[J].理化检验:化学分册,2005,41(Z1):26-27

,31.

国家环境保护总局,空气和废气监测分析方法编委会.空气和废气监测分析方法[M].4版.北京:中国环境科学出版社,2003:21,193-253.

Center for Environmental Research Information Office of Reserch and Development. Compendium Method I.O-3.3,Determination of metals in ambient particulate metter using X-ray fluorescence (XRF) spectroscopy . Washington: Environmental Protection Agency, 1999.

Elike Adriaenssens. Airbone-heavy metals analysis over Belgium [M]. PANalytical Corporation, 2007:1,4-6.

郑南,吉昂,王河锦,徐廷婧,李婷.北京市冬季霾天气可吸入颗粒物的矿物学研究[J].北京大学学报:自然科学版,2009,45(5):825-836.

吉昂,李国会,张华.高能偏振能量色散X射线荧光光谱仪应用现状和进展[J].岩矿测试,2008,27(6):451-462.

Vuong T B, Kregsamer P, Markowicz A. Element sensitivity method in XRF analysis of PM₁₀ aerosol filters[J]. Nuclear Science and Technology, 2003,2(2):18-28.
