车载小型气体质谱仪现场地气分析应用
Application of Vehicle-Mounted Miniature Gas Mass Spectrograph in Onsite Geogas Analysis
-
摘要: OmniStar小型气体质谱仪用于车载实验室,可根据野外情况采取灵活的采样方式,实现对H2、He、CH4、N2、O2、Ar、CO2以及C3H8、C4H10的现场分析。对浓度为100×10-6的H2、He、CH4、N2、O2、Ar、CO2混合标气进行100次连续测定得到的各组分的精密度(RSD)均优于1％,H2、He、Ar、CO2准确度(RD)分别为3.74、0.94、1.83、10.5;对室内空气进行连续3500次测定得到的H2、He、CO2的精密度分别为2.25％、5.55％、4.06％,N2、O2、Ar的精密度优于1％;对CH4、C2H6、C3H8、C4H10混合标准气体进行连续13次测量得到的C3H8、C4H10的精密度(RSD)优于1％,测量平均值与标准值完全吻合,能够满足野外现场分析需求。在内蒙古西乌旗及新疆金窝子地区应用该仪器,采用采样袋取气、螺旋钻及井孔原位在线测定等方式得到样品数据,并发现两区域内部分采样点的CO2、H2及He异常。Abstract: OmniStar miniature gas mass spectrograph has been used in a vehicle-mounted laboratory and realizes the on-line analysis of H2, He, CH4, N2, O2, Ar, CO2, C3H8 and C4H10 with flexible sampling modes according to the actual field condition. Statistical data from 100 consecutive analysis of a mixed standard gas for components of H2, He, N2, O2, Ar, CO2 at concentration of 100 10-6 show that the analytical precision is less than 1% RSD and the analytical accuracies (RE) of H2, He, Ar, CO2 are 3.74%, 0.94%, 1.83% and 10.5% respectively. Statistical data from 3500 consecutive analysis for the indoor air sample show that the analytical precision (RSD) of H2, He, CO2 are 2.25%, 5.55%, 4.06% respectively and analytical precision of N2, O2, Ar are less than 1% RSD. Statistical data from 13 consecutive measurements of a mixed standard gas sample for CH4, C2H6, C3H8, C4H10 shows that the analytical precision of C3H8 and C4H10 are less than 1% RSD and the average values for each analyte are in agreement with standard values. High accurate measurement results satisfy the requirements of field onsite analysis. The apparatus along with twist drilling and bag gas sampling has been used in on-line analysis of gases in geological survey regions of Xiwuqi of Inner mongolia and Jinwozi of Xinjiang and the abnormal concentration of CO2, H2 and He are found in some sampling sites.
-
Keywords:
- vehicle-mounted /
- laboratory /
- miniature /
- gas /
- mass
-
-
张铭杰,王先彬,李立武.地幔流体组成[J].地学前缘,2000, 7(2):401-412. 杜乐天.地球的五个气圈与氢烃资源[J].矿地质,1993(5):257-264 . Francois G..Geochemistry:Earth’s innermost [J].Nature,1994,369:360-361. Francois G..Geochemistry:Earth’s innermost [J].Nature,1994,369:360-361.
Hofmann C, Courtillot V, Feraud G. Timing of the Ethiopian flood basalt event and implications for plume birth and global change[J].Nature,1997,389:838-841. Hofmann C, Courtillot V, Feraud G. Timing of the Ethiopian flood basalt event and implications for plume birth and global change[J].Nature,1997,389:838-841.
Allegre C J,Staudacher T, Sarda P. Rare gas systematics: Formation of the atmosphere, evolution and structure of the Earth's mantle[J]. Earth and Planetary Science Letters, 1986/1987,81:127-150. Allegre C J,Staudacher T, Sarda P. Rare gas systematics: Formation of the atmosphere, evolution and structure of the Earth's mantle[J]. Earth and Planetary Science Letters, 1986/1987,81:127-150.
Snyder G, Taylor L A, Jerde E A. Archean mantle heterogeneity and the origin of diamondiferous eclogites. Siberia: Evidence from stable isotopes and hydroxyl in garnet[J].American Mineralogist, 1995,80:799-809. Snyder G, Taylor L A, Jerde E A. Archean mantle heterogeneity and the origin of diamondiferous eclogites. Siberia: Evidence from stable isotopes and hydroxyl in garnet[J].American Mineralogist, 1995,80:799-809.
Peacock S M. Fluid processes in subduction zones[J]. Science, 1990,248:329-337. Peacock S M. Fluid processes in subduction zones[J]. Science, 1990,248:329-337.
Turner S, Haw Kesworth C. Constraints on flux rates and mantle dynamics beneath island arcs from Tonga-Kermadec lava geochemistry[J]. Nature,1997,389:568-573. Turner S, Haw Kesworth C. Constraints on flux rates and mantle dynamics beneath island arcs from Tonga-Kermadec lava geochemistry[J]. Nature,1997,389:568-573.
上官志冠,郑雅琴,董继川.长白山天池火山地热区逸出气体的物质来源[J].中国地质,1997,27(4):318-342. 孙青,李圣强,罗立强.中国大陆科学钻探工程主孔地下流体特征及与地震活动的关系初步研究[J].地震,2005,25 ( 1) :15-21. 李圣强,孙青,罗立强,詹秀春.中国大陆科学钻探主孔流体异常与其附近2次ML3.9级地震的关系[J].中国地质,2005,32( 2):330-335. 孙青,李圣强,罗立强,詹秀春.中国大陆科学钻探主孔流体地球化学异常与远强震的关系[J].岩石学报,2005,21(5):1501-1507. 周子勇,陶澎.地气的宏观效应与微观效应[J].地学前缘,2003,10(1):249-255. 工先彬,徐胜,陈践发.腾冲火山区温泉气体组分和氦同位素组成特征[J].科学通报,1993,38(9):814- 817. 工先彬,陈践发,徐胜.地震区温泉气体的地球化学特征[J].中国科学:B辑,1992,22( 8) :849- 854. 杜乐天.自然灾害可能的深部流体肇因[J].地学前缘,1996,3(4):298-305. 童纯菡,李巨初.地气测量寻找深部隐伏金矿及其机理研究[J].地球物理学报,1999,42(1):135-142. 张铭杰,王先彬,胡沛青,张昱,叶先仁,李立武.地幔流体化学组成与成烃[J].天然气地球科学,2006,17(1):31-35. 叶先仁,方念乔,丁林,张铭杰.麦哲伦海山富钴结壳的稀有气体丰度及He、Ar同位素组成[J].岩石学报,2008,24(1):185-192. 李迎春,唐力君,王健,张宝科,李松,詹秀春,罗立强.小型气体质谱仪在中国人陆科学钻探钻井现场泥浆中气体的在线分析应用[J].岩矿测试,2008,27(1):1-4. 唐力君,李迎春,王健,张宝科,李松.中国大陆科学钻探工程现场实验室采样及样品处理方法探讨 [J].中国地质,2006,33(5):1174-1179. 罗立强,王健,李松.中国大陆科学钻探现场分析与地下流体异常识别[J].岩矿测试, 23(2):81-86. 詹秀春,罗立强,李迎春,唐力君,李东.中国大陆科学钻探主孔4906米附近氦气体异常的解析[J].岩矿测试,2006,25(1):1-4. 李圣强,孙青,詹秀春.中国大陆科学钻探主孔0~2000米流体地球化学异常与地震的关系[J].岩石学报,2006,22(7):2095-2102. 曾令森,詹秀春,梁凤华,罗立强,许志琴.苏鲁超高压变质岩区深部流体He-Ar的系统关系:中国大陆科学钻探工程在线流体监测的解析[J].岩石学报,2005, 21(2):513-520. 詹秀春,罗立强,李迎春,唐力君,李东.关于CCSD主孔4820~4930m井段气体异常的初步解释[J].中国地质,2005,32(2):320-329. 罗立强,孙青,詹秀春.中国大陆科学钻探主孔0~2000米流体剖面及流体地球化学研究[J].岩石学报,2004,20(1):185-191.
